Lithmate
1 / 4
| Item | Parameter | LMS12120 |
|---|---|---|
| Nominal | Voltage | 12V |
| Capacity | 120Ah | |
| Physical | Dimension | 330*172*235mm (13x6.77x9.25") |
| Weight | 16KG (35.27lb) | |
| Electrical | Charge Voltage | 15.8V |
| Cut-off Voltage | 8V | |
| Continuous Discharge Current | 100A | |
| Peak Discharge Current | 200A | |
| CCA | 1300 | |
| Others | Working Temperature | -40-80℃ |
| Cycle Life | >3,500 Cycles |
This battery has a nominal voltage of 12V and a nominal capacity of 120Ah.
The physical dimensions are 330*172*235mm (13x6.77x9.25 inches), and it weighs approximately 16KG (35.27lb).
The battery is designed for durability, offering a long service life with more than 3,500 cycles.
This battery is capable of operating in extreme conditions, with a working temperature range of -40℃ to 80℃.
The battery supports a continuous discharge current of 100A and can handle a peak discharge current of up to 200A.
The recommended charge voltage for this battery is 15.8V, and the safety cut-off voltage is 8V.
