| Electrical Specifications | |
| Nominal voltage | 25.6V (24V System) |
| Nominal capacity | 160Ah |
| Energy | 4.09Kwh |
| Cycle life | >4,000 cycles |
| Remote diagnostics and upgradation | Optional |
| Heating system | Optional |
| Mechanical Specifications | |
| Dimensions (L x W x H) | 624*210*627mm (24.57x8.27x24.69") |
| Weight | 36KG (79.3lb) |
| Case material & IP rating | Steel, IP67 |
| Charge & Discharge Specifications | |
| Charge current | 150A |
| Continuous discharge current | 160A |
| Peak discharge current | 480A (30s) |
| Max. charge voltage | 29.2V |
| Cut-off voltage | 20V |
| Battery management system (BMS) | Yes, built-in BMS |
