Lithmate
1 / 4
| Item | Parameter | LM12200 |
|---|---|---|
| Nominal | Voltage | 12.8V |
| Capacity | 200Ah | |
| Physical | Dimension | 345*190*245mm (13.58x7.48x9.65”) |
| Weight | 20.6KG (45.4lb) | |
| Electrical | Charge Voltage | 14.6V |
| Cut-off Voltage | 10V | |
| Charge Current | 100A | |
| Continuous Discharge Current | 200A | |
| Peak Discharge Current | 400A | |
| Others | Working Temperature | -20 - 65℃ |
| Storage Temperature | 0 - 45℃ | |
| Cycle Life | >4,000 Cycles |
The LM12200 battery offers an exceptional cycle life of more than 4,000 cycles, providing long-lasting and reliable power compared to traditional lead-acid options.
The battery supports a continuous discharge current of 200A and can handle a peak discharge current of up to 400A for heavy power requirements.
The LM12200 features a compact design, measuring 345*190*245mm (13.58x7.48x9.65 inches) and weighing approximately 20.6KG (45.4lbs) for easy installation.
The working temperature range is -20°C to 65°C, while the safe storage temperature range is 0°C to 45°C, making it suitable for various environmental conditions.
The nominal charging voltage is 14.6V, and the low-voltage cut-off is configured at 10V to protect the battery cells from deep discharge.
