Lithmate
1 / 4
| Item | Parameter | LM12304 |
|---|---|---|
| Nominal | Voltage | 12.8V |
| Capacity | 304Ah | |
| Physical | Dimension | 345*190*245mm (13.58x7.48x9.65”) |
| Weight | 28KG (61.73lb) | |
| Electrical | Charge Voltage | 14.6V |
| Cut-off Voltage | 10V | |
| Charge Current | 100A | |
| Continuous Discharge Current | 200A | |
| Peak Discharge Current | 400A | |
| Others | Working Temperature | -20-65℃ |
| Storage Temperature | 0-45℃ | |
| Cycle Life | >4,000 Cycles |
The LM12304 battery has a nominal voltage of 12.8V and a rated capacity of 304Ah, providing a stable and reliable power source for heavy-duty applications.
This high-quality LiFePO4 battery offers an exceptional lifespan of over 4,000 cycles under standard operating conditions before its capacity begins to gradually reduce.
The battery supports a standard continuous discharge current of 200A and can handle a peak discharge current of up to 400A for short durations.
The physical dimensions are 345*190*245mm (equivalent to 13.58x7.48x9.65 inches), and it has a total weight of 28KG (61.73 lbs).
The battery operates effectively in working temperatures ranging from -20°C to 65°C. For long-term storage, it is recommended to keep the battery in an environment between 0°C and 45°C.
The recommended charge voltage is set at 14.6V with a standard charge current of 100A. The built-in safety cut-off voltage is configured at 10V to prevent over-discharging.
