Lithmate
1 / 4
| Electrical Specifications | 24V |
| Nominal voltage | 25.6V |
| Nominal capacity | 304Ah |
| Energy | 7.78Kwh |
| Cycle life | >4,000 cycles |
| Accessories | Buzzer, Display, Charger Optional |
| Remote diagnostics and upgradation | Optional |
| Fireproof | yes, and come with fire extinguisher optional |
| Mechanical Specifications | |
| Dimensions (L x W x H) | 624x284x627mm(24.57x11.18x24.69") |
| Weight | 230KG(507.1lb) |
| Case material & IP rating | Steel, IP67 |
| Charge & Discharge Specifications | |
| Charge current | 200A |
| Continuous discharge current | 230A |
| Peak discharge current | 460A |
| Max. charge voltage | 29.2V |
| Cut-off voltage | 20V |
| Battery management system(BMS) | Yes, built-in BMS |
1. What is the nominal capacity and energy output of this battery?
This battery features a nominal capacity of 304Ah and delivers a total energy output of 7.78Kwh, operating at a nominal voltage of 25.6V.
2. How many cycles does this battery last?
The battery provides an exceptional lifespan with a cycle life exceeding 4,000 cycles, offering long-term reliability and efficient performance.
3. What is the IP rating and casing material of the battery?
The battery is constructed with a robust steel case and has an IP67 rating, offering high resistance to water and dust ingress for demanding environments.
4. Is there an integrated Battery Management System (BMS)?
Yes, the battery comes with a built-in Battery Management System (BMS) to ensure safe charge and discharge rates and general performance monitoring.
5. What safety features are available for fire prevention?
The battery is fireproof and offers an optional configuration that includes a dedicated fire extinguisher system for enhanced industrial safety.
6. Can the battery firmware be updated or diagnosed remotely?
Yes, remote diagnostics and upgrade functions are available as optional features to ensure easy maintenance and system updates.
