Lithmate
1 / 4
| Item | Parameter | LM12020 |
|---|---|---|
| Nominal | Voltage | 12.8V |
| Capacity | 20Ah | |
| Physical | Dimension | 181*77*170mm (7.13x3.03x6.69") |
| Weight | 2.5KG (5.51lb) | |
| Electrical | Charge Voltage | 14.6V |
| Cut-off Voltage | 10V | |
| Charge Current | 10A | |
| Continuous Discharge Current | 20A | |
| Peak Discharge Current | 40A | |
| Others | Working Temperature | -20-65℃ |
| Storage Temperature | 0-45℃ | |
| Cycle Life | >4,000 Cycles |
The LM12020 battery has a nominal voltage of 12.8V and a nominal capacity of 20Ah, providing stable and reliable power delivery.
The physical dimensions of the battery are 181*77*170mm (7.13x3.03x6.69"), and it has a lightweight design weighing only 2.5KG (5.51lb).
This battery features an outstanding cycle life, engineered to last for more than 4,000 cycles under standard operating conditions.
The LM12020 supports a charge voltage of 14.6V with a charge current of 10A. It allows a continuous discharge current of 20A and can handle a peak discharge current up to 40A.
The working temperature range for operation is -20℃ to 65℃, while the recommended storage temperature range is 0℃ to 45℃.
