OEM Electric Golf Trolley Battery 12V 24Ah Lithium LiFePO4 Supplier, Suppliers

Upgrade your golfing experience with our high-performance 12V 24Ah Lithium LiFePO4 battery, designed specifically for electric golf trolleys. Lightweight yet powerful, this battery offers exceptional energy efficiency, longer runtime, and faster charging compared to traditional lead-acid batteries.

Send Inquiry

Product Description

Product Specifications

Electrical Specifications
Nominal Voltage	12.8V	12.8V
Nominal Capacity	18Ah	24Ah
Energy	230.4wh	307.2wh
Cycle Life	>4000 cycles
Mechanical Specifications
Dimensions (L x W x H)	16812875mm (6.61x5.04x2.95")	168128101mm (6.61x5.04x3.98")
Weight	2.6KG (5.7lb)	3KG (6.6lb)
Terminal Type	O
Case Material & IP Rating	ABS, IP67
Charge & Discharge Specifications
Charge Current	4A	4A
Continuous Discharge Current	18A	25A
Peak Discharge Current	36A	50A
Max. Charge Voltage	14.6V	14.6V
Cut-off Voltage	10V	10V
Battery Management System (BMS)	Yes, built-in BMS protection

Product Presentation

12V Lithium Battery Specification Display

Frequently Asked Questions

What is the expected lifespan of these batteries?

These batteries offer an exceptional cycle life of over 4000 cycles, providing long-term reliability and performance compared to standard lead-acid alternatives.

Are the batteries protected against overcharge or short circuits?

Yes, every battery comes with a built-in Battery Management System (BMS) that provides comprehensive protection against overcharging, deep discharging, and other potential electrical issues.

Can these batteries be used in wet or outdoor environments?

The batteries are housed in a durable ABS case with an IP67 rating, making them highly resistant to dust and capable of withstanding immersion in water up to 1 meter.

What is the difference between the 18Ah and 24Ah models?

While both share the same 12.8V nominal voltage, the 24Ah model provides higher energy capacity (307.2Wh) and higher continuous/peak discharge currents compared to the 18Ah model.

What is the recommended charging voltage?

The maximum charge voltage for these 12.8V units is 14.6V, which ensures optimal charging efficiency and battery health.

What kind of terminals do these batteries use?

These models are equipped with Type O terminals, designed for secure and stable electrical connections.
